Mini Cooper F56 KW Suspension – Street Performance Coilover V3 Inox

KW Suspension Street Performance Coilovers V3 Inox For The Mini Cooper / S / JCW (F56). High Quality German Coilovers. Adjustable Rebound & Compression.

Similar to the racing coilovers from the KW Racing program, the KW V3 can be adjusted independently in compression and rebound damping. This individual adjustment possibility is much appreciated by sports car manufacturers, tuners and drivers worldwide.

If you have already made your first performance modifications to your vehicle the KW V3 coilover will compliment your upgrades. The patented KW-valve technology for separate adjustment of rebound and compression damping allows you to individually setup your suspension. The adjustable KW bottom valve adjusts the low-speed range of the compression level in twelve clicks.

You don’t need any adjusting tools because of the compression adjuster at the lower end of the stainless steel housing. The adjustable compression damping with its twelve exact clicks allows you to manually influence body roll, without having to change the spring rate which optimally matches the rebound.

With the individually adjustable rebound setup of the KW V3 you can directly influence the handling and comfort with its precise click adjustment. Depending on the vehicle type, the rebound valves of the KW twin-tube dampers on the upper end of the piston rod will be adjusted via an integrated adjustment wheel or a twist-adjustment wheel which is included in the delivery content.

By increasing the rebound force via the adjustment wheel body movements are reduced. You will have more stability during high speed cornering. If you change for example the wheel / tire combination (approved by the car manufacturer) to larger wheels, then with a KW V3 you will be able to adjust the car’s handling perfectly.

By the individual lowering with its continuous adjustment range, you can emphasize the sportiness of your vehicle visually. A feature that is very popular in the performance-oriented tuning scene.

The KW V3 coilover kit is the perfect accessory for performance-oriented drivers and tuning enthusiasts who put a great demand on their suspension. The separately rebound and compression damping adjustable dampers with their “well-thought-through” click adjustment allow a perfect setup. So it is easy to influence the steering behaviour, directional stability, tire grip and handling characteristics when driving on the limit.

Electronic Damping

Depending on your vehicle there are two options available depending if your vehicle currently has electronic damping or not. If your vehicle currently has electronic damping then a deactivation kit is included with the kit. Please make sure you choose from the drop-downs above the correct option for your vehicle.

Top Features

• Rebound and compression damping adjustable damper technology
• Stainless steel technology “inox-line”
• Individual, continuous lowering
• Tested adjustment range
• High quality components for a long life
• Complete documentation for an easy handling
• Adjustable rebound damping with 16 exact clicks
• Adjustable compression damping with 12 exact clicks
• Unique, independent from each other working damping force adjustment

YouTube Video

This will be on our channel very soon

Specifications

• Damping Adjustment: Rebound & Compression Damping
• Product Line: Street Performance
• Lowering FA/RA: 20-45mm / 20-45mm
• Adjustment FA/RA: Thread / Thread
• Material: Stainless Steel
• Axle Load FA/RA: -1050kg / -915kg

Installation

We’re able to offer installation of this system to your vehicle at our workshop here in Poole, Dorset.

Typically installation for a system like this should take approximately 6-8 hours to complete. As part of the installation a 4-wheel alignment must be carried out once the suspension has been completed.

Please get in touch for more info on the installation aspect and pricing.

Compatibility:

• Mini Cooper (F56) – 2013+
• Mini Cooper S (F56) – 2013+
• Mini Cooper JCW (F56) – 2013+

If you are unsure of fitment, please get in touch with us before purchasing. If you would like an up to date stock level check, please do get in touch.

Please Note:

• Possible drop measurement is based on a brand new vehicle from factory. The amount the car will lower by may vary depending on the age / mileage of your vehicle.
• Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers)
• Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
• For rear axle camber adjustment we recommend the installation of the car specific adjustable control arm set from KW. The part number for the control arm set is mention in the accessories list
